Visual Productions CueCore3
£1,540.00
Powerful architectural lighting controller
The CueCore3 is a smart and compact solid state controller for (semi) permanent installations, architectural lighting and system integration projects. It is a standalone device for 24/7 non-stop-operation. Capable of playing back lighting shows, static scenes and dynamic effects through its 4 DMX ports. The intelligent web based programming, fast CPU and the 6GB flash memory allow for impressive performance. Record, control, interface and playback.
Delivery Lead Time: 5-10 working days approx.
Specifications
| Ethernet port |
|
Programming via web-interface |
|
4 x DMX512-A (ANSI E1.11) port (Opto-isolated, bi-directional) |
|
RDM |
|
MIDI IN + OUT (inc. MTC, MSC, MMC) |
|
SMPTE timecode |
|
4x GPI port (contact-closure or 0-10V) |
|
Real-Time Clock with battery |
|
Art-Net, sACN, KiNet |
|
HTTP, TCP, UDP & OSC |
|
Protocol for synchronising multiple cores. |
|
9-24V DC 500mA (PSU included) |
|
Power over Ethernet (class III) |
|
Desktop,DIN Rail or 19” rack mounted (optional adapter) |
|
Kensington lock |
|
Operating temperature -20°C to +50°C (-4°F to 122°F) |
|
Compatible with Kiosc software |
|
Bundled with CueluxPro and vManager software |
|
Compliance CE, ROHS, UKCA, FCC, UL62368-1, CSA C22.2 62368-1:19 |
